Jump to an exact size
1,746 sizes in 7 materials. Pick OD, ID and thickness to jump straight to the product.
Rubberwasherwarehouse
Rubber Washer 1-3/4" OD x 7/8" ID x 3/16" Thick
Regular price $4.99Unit priceRubberwasherwarehouse
Rubber Washer 1-3/4" OD x 7/8" ID x 3/32" Thick
Regular price $4.99Unit priceRubberwasherwarehouse
Rubber Washer 1-3/4" OD x 7/8" ID x 1/16" Thick
Regular price $4.99Unit priceRubberwasherwarehouse
Rubber Washer 1-5/8" OD x 7/8" ID x 3/16" Thick
Regular price $4.99Unit price
About 7/8" ID Rubber Washers
7/8" ID rubber washers have a 7/8" (22.2 mm) hole, so they slip over a 7/8" bolt, stud, rod, pipe or tube, or the nearest metric size, M22. We list 91 of them, with outside diameters from 1-1/8" to 4" and the thicknesses in the table below, each in neoprene, EPDM, nitrile, silicone, natural rubber, Viton and fiber. Pick the OD for how much surface the washer must cover, and the thickness for the gap it seals.
7/8" ID sizes in stock now
- 1-1/8" OD x 7/8" ID x 1/8" thick: Neoprene, from $0.40 each
- 1-1/4" OD x 7/8" ID x 3/32" thick: Neoprene, from $0.41 each
- 1-1/4" OD x 7/8" ID x 1/4" thick: Neoprene, from $0.53 each
- 1-1/2" OD x 7/8" ID x 1/8" thick: Neoprene, from $0.47 each
Stock changes daily; each product page shows what ships today.
Every 7/8" ID size we list
| Outside diameter (OD) | Thicknesses listed |
|---|---|
| 1-1/8" (28.6 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 1-1/4" (31.8 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 1-3/8" (34.9 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 1-1/2" (38.1 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 1-5/8" (41.3 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 1-3/4" (44.5 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 2" (50.8 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 2-1/4" (57.2 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 2-1/2" (63.5 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 2-3/4" (69.9 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 3" (76.2 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 3-1/2" (88.9 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
| 4" (101.6 mm) | 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2" |
Choosing a 7/8" ID washer
The hole should be a snug fit: rubber stretches a little, so a washer that is a touch tight slides on and seals, while one more than about 1/32" loose can shift off-centre. Choose an OD at least twice the hole for a bolt head or nut to bear on, larger to spread load on soft surfaces. The washer size by bolt chart and the measuring guide help you confirm the size.
FAQ
What does 7/8" ID mean?
ID is the inside diameter, the hole: 7/8" (22.2 mm) across. The overall size is the OD, from 1-1/8" to 4" for this hole size.
Will a 7/8" ID washer fit a metric bolt?
The closest metric bolt is M22. For the full list see metric rubber washers.
What if my size or material is sold out?
Use the custom size calculator for an instant price on any OD, ID and thickness in neoprene, EPDM, silicone or Viton (made to order in the USA, about 4 weeks), or tap "Email me when this size is back" on the product page.
Which material should I choose?
Neoprene is the all-round choice for water, weather and general sealing; EPDM for outdoor, UV and hot-water use; nitrile (NBR) for oil and fuel; silicone for high heat and food contact; Viton (FKM) for fuel and chemicals; natural rubber for cushioning; fiber for rigid, insulating seals. The material comparison has the full chart.
Buying in quantity? Bulk pricing applies automatically per size at checkout: 10% off 100+ pieces, 15% off 250+, 20% off 500+ and 30% off 1,000+. See wholesale rubber washers.
Related: 7/8" OD rubber washers, rubber washer size chart, size finder.
